Catchup call gen with Timer Tick of 1 second


A call generator can be summarised as: make next Call, wait Inter Arrival Time. A call generator could be implemented by starting a timer for the InterArrivalTime. Alternatively, OnTimerTick, send enough calls to make wanted call rate. When Timer Tick >> Average Inter Arrival Time, The call generator is very bursty. A simulation can be used to explore NegExp Traffic.
A fixed timer tick occurs. Call Inter Arrival Times are accumulated until simulated time catches up with real time.

Tick Timer Time. Average InterArrival Time.( or 1 / average callRate )
update simulation. update call graph. image alt text.
InterArrivalTime modulation: constant. uniform. neg exp. constant+uniform 10% constant + 90% uniform

Lookup Table: iatArraySize or num of samples in table.
Table populated: constant. uniform distribution. neg exp. log. 0.1 & 1.9 constants
0.9 & 1.1 constants


Theory - Catch Up Call Generator

// wait InterArrivalTime OnTimerTick(){ makeCall(); startTimer( interArrivalTime ) } // Wait fixed time, send enough calls. OnTimerTick(){ catchUpCalls(); startTimer( tickTimerTime ) }

Theory - An ideal call generator

Make a call, wait the exact time to the next based on ideal requirements.



  interArrivalTime = -Math.log(1-Math.random( ))  / CallsPerSecond;

  while( true ) {
    sendCall();  // Call Opportunity - pick source,destination and call type
    wait( InterArrivalTime )
  }

This is like an oscillator, clocking the network. The oscillator may modulate the time between ticks using a distribution.

For each call pick the source, destination and call type.

The source and destinations can be the phone dialling a particular phone number or maybe the phone's exchange and the terminating phone number routed via a common exchange.

Theory - Catch Up Call Generator

The system only has a constant time tick and the required inter arrival times are sometimes shorter than the the minimum tick timer that the call generator can provide. The call generator sometimes has to send multiple calls per timer tick.

Constant InterArrival Times:

Negative Exponential Distributed InterArrival Times:



while( true ) {
  timeSlice()
  wait( timerTick )
}


function timeSlice() {

  // nowTime is simulated and as precise as required.
  // This is run once per time slice.
  // Normally this would go as fast at the hardware allows.

  // Move simulated time on by timerTick
  // nowTime is relative to real time
  nowTime = nowTime - timerTickTime;

  calls=0
  if ( nowTime > 0.0 ) {
    // No calls needed
  } else {
    // Catch up simulated time with real time
    while ( nowTime  < 0.0 ){
      //# Catch up with calls as simulated time is behind real time
      //# generate a time interval modulated by Neg Exp distribution
      // interArrivalTime = -Math.log(1-Math.random( ))  / CallsPerSecond;
      interArrivalTime = calculateNextInterArrivalTime( CallsPerSecond );
      sendCall();  // Call Opportunity - pick source,destination and call type
      nowTime = nowTime + interArrivalTime;
    }
  }
}


Look up table

The l More Theory ...
